Home / Solutions / Irrigation
Built for :
Irrigation
In regions with developing agricultural practices, farmers
can only growing crops during the rainy season due to limited irrigation. With Samking, it's possible to cultivate up to three seasons a year. This boost in productivity has increased their income and eliminated water shortages in dry season.
01/05
What’s the Power
Behind it:
•
The system reduces electricity costs and offers an eco-friendly solution for pool maintenance.
•
A solar-powered pool pump uses energy from solar panels to power the pump, circulating water through the filter without relying on the electric grid.
•
Offering a hybrid AC/DC power source, ensuring reliable water circulation in all weather conditions, with solar panels installable on the roof or in a sunny yard spot.
02/05
Whether installing a new system or upgrading an existing one, we'll guide you through the essential information you need to get started.
Build an Effective
Watering System:
01- Learn How to Pick the
Ideal Solar Pump
Considering your water source, lift, distance, daily needs, Ensure the pump's head and flow rate match your requirements, pair it with appropriately sized panels.
• What is the water source? (Borehole or River)
• Lift from the water surface to the ground? (H1)
• Horizontal distance of water transport? (L)
• The daily water requirement? (m³/day)
• Height of the tank? (H2)
ACTUAL LIFT HEAD
= H1 + H2 + 10%L
KEY CRITERIA (1)
Model Max H * 70% > H1 + H2 + 10%L >
Max Head * 30%
KEY CRITERIA (2)
Model Max F >
Daily Water Requirement (m³/Day)
02- Calculate Lift & Head
03- Select the
Right Solar Panels
The solar panel array should be 1.3 times the water pump's power, with voltage matching the pump's range. (For the 0.3-3HP SAMKING Solar Pump Family, we recommend connecting panels in series.)
E.g.,5 Panels Connected in Series:
(410W, Vmp: 38.5V, Voc: 42.6V)
F Power = 5 x 410W = 2200W
F Vmp = 5 x 38.5V = 192.5V
F Voc = 5 x 42.6V = 213V
Ensure*
F Power ≥ Pump Power x 1.3
F Voc < Pump's Max Voc
DC Working Voltage Range (Economic Models)
Rated Power
300W/0.3HP
600W/0.5HP
1000W/0.75HP
1200W/1HP
1800W/1.5HP
2200W/2HP
3000W/3HP
Rated Voltage
20-40Vmp / Voc ≤ 48V
40-76Vmp / Voc ≤ 96V
65-110Vmp / Voc ≤ 150V
80-150Vmp / Voc ≤ 180V
110-250Vmp / Voc ≤ 440V
150-300Vmp / Voc ≤ 440V
250-380Vmp / Voc ≤ 440V
03/05
See Our
Proven Cases
Chiangmai, Thailand
Agriculture drives 18.64% of Thailand’s GDP, contributing employing 48% of the labor force. With 87% of irrigation pumps diesel-powered, costs are high for farmers.
Samking’s solar irrigation system revolutionised farming
in Rangpur, supplying water to 30 farmers.
This transformative solution enabled farmers to increase their crop production cycles from just one to three harvests annually. With the ability to irrigate 20 acres of rice fields and 50 acres of vegetable crops, agricultural productivity has reached new heights. Result in a sustainable system.
04/05
Chosen Models for
Irrigation
3SPN2-16
Max H:
Max F:
Max Voc:
Rated Power:
120 M
5.0 m³/h
200 V
1,500 W
4SPN5-15
Max H:
Max F:
Max Voc:
Rated Power:
170 M
9.7 m³/h
450 V
3,000 W
5SP10-5
Max H:
Max F:
Max Voc:
Rated Power:
94 M
31.6 m³/h
440 V
5,100 W
5SP30-2
Max H:
Max F:
Max Voc:
Rated Power:
40 M
52.5 m³/h
440 V
5,100 W
05/05
